09642247243
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Board Lock Filter Grounding Indents Mounting Brackets Gold Plug, Male Pins Connector -20C~125C 7.5A 100V 0.406 (10.30mm)
PDF
/
Inventory: 3746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
IEC Conformance NO
Filter Feature YES
Contact Type Signal
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 7.5A
Total Number of Contacts 15
Reach Compliance Code compliant
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Empty Shell NO
Flange Feature Board Side (M3)
Connector Style D-Sub
Contact Form Machined
Shell Size, Connector Layout 2 DA A
Backset Spacing 0.406 (10.30mm)
DIN Conformance NO
MIL Conformance NO
Additional Feature PANEL MOUNTABLE
Voltage - Rated 100V
Number of Rows 2
Color Natural
Number of Positions 15
Connector Type Plug, Male Pins
Termination Solder
Part Status Active
Feature Board Lock, Filter, Grounding Indents, Mounting Brackets
Packaging Bulk
Operating Temperature -20°C~125°C
Compliance
Material Flammability Rating UL94 V-0
Physical
Shell Material, Finish Steel
Dielectric Material Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Insulation Material GLASS FILLED PCT
Mounting Type Through Hole, Right Angle
Contact Material Copper Alloy
