09642127226
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
TIN GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Board Lock Filter Receptacle, Female Sockets Connector -20C~125C 7.5A 100V
PDF
/
Inventory: 2846
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mounting Type Through Hole
Insulation Material GLASS FILLED POLYESTER
Dielectric Material Polycyclohexylenedimethylene Terephthalate (PCT)
Shell Material, Finish Steel, Tin Plated
Technical
Operating Temperature -20°C~125°C
Packaging Bulk
Feature Board Lock, Filter
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 15
Color Natural
Number of Rows 2
Voltage - Rated 100V
Additional Feature PANEL MOUNTABLE
HTS Code 8536.69.40.30
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Contact Type Signal
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 7.5A
Total Number of Contacts 15
Reach Compliance Code compliant
Shell Finish TIN
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Empty Shell NO
Flange Feature Board Side (M3)
Connector Style D-Sub
Contact Form Machined
Shell Size, Connector Layout 2 DA A
Compliance
Material Flammability Rating UL94 V-0
