09564005615050
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Connector
PDF
/
Buying Options
Total Price: USD $11.63
Unit Price: USD $11.626349
≥1 USD $11.626349
≥10 USD $10.968249
≥100 USD $10.34741
≥500 USD $9.761704
≥1000 USD $9.209163
Inventory: 2810
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Through Hole
Mounting Type Free Hanging (In-Line)
Dielectric Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Housing Material PBT
Shell Material, Finish Steel, Tin Plated
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Feature Grounding Indents
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 62
Color Black
Number of Rows 3
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Signal
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.42mm
Total Number of Contacts 62
Orientation Straight
Current Rating 2A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Empty Shell NO
Wire Gauge 24 AWG
Flange Feature Housing/Shell (Unthreaded)
Connector Style D-Sub, High Density
Contact Form Stamped
Shell Size, Connector Layout 4 DC C High Density
Dimensions
Length 69.4mm
Width 12.55mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
