09564004715050
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Connector
PDF
/
Buying Options
Total Price: USD $14.01
Unit Price: USD $14.0096
≥1 USD $14.0096
≥10 USD $12.4168
≥100 USD $11.939488
≥500 USD $11.461824
≥1000 USD $10.825144
≥3000 USD $9.869974
Inventory: 147
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Width 12.55mm
Length 69.4mm
Technical
Shell Size, Connector Layout 4 DC C High Density
Contact Form Stamped
Connector Style D-Sub, High Density
Flange Feature Housing/Shell (Unthreaded)
Wire Gauge 24 AWG
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 2A
Orientation Straight
Total Number of Contacts 62
Pitch 2.42mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Signal
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Receptacle
Number of Rows 3
Color Black
Number of Positions 62
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Shell Material, Finish Steel, Tin Plated
Housing Material PBT
Dielectric Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 9 Weeks
