09551566616741
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
ROHS3Compliant Nickel GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Receptacle, Female Sockets Connector -55C~125C 5A 2.76mm
PDF
/
Buying Options
Total Price: USD $7.54
Unit Price: USD $7.5416
≥1 USD $7.5416
≥10 USD $6.78568
≥100 USD $6.39232
≥500 USD $6.228464
Inventory: 192
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Phosphor Bronze
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Shell Material Steel
Dielectric Material Liquid Crystal Polymer (LCP)
Housing Material Polymer
Shell Material, Finish Steel, Nickel Plated
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature Board Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 9
Color Black
Number of Rows 2
Gender Female
Additional Feature LOW PROFILE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Signal
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.76mm
Total Number of Contacts 9
Current Rating 5A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Flange Feature Housing/Shell (4-40)
Plating Nickel
Connector Style D-Sub
Contact Form Stamped
Shell Size, Connector Layout 1 DE E
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
