634-044-263-142
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub High Density Connectors D SUB RECEPTACLE RA HD .350 FP
PDF
/
Inventory: 5235
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness Flash
Technical
Backset Spacing 0.350 (8.89mm)
Shell Size, Connector Layout 3 DB B High Density
Connector Style D-Sub, High Density
Flange Feature Housing/Shell (4-40)
Contact Finish Gold
Current Rating 5A
Current Rating (Amps) 3A
Contact Type Signal
Number of Rows 3
Color Black
Number of Positions 44
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock, Shielded
Series 634
Published 2011
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Shell Material, Finish Steel, Nickel Plated
Housing Material Polyester
Dielectric Material Polyester Thermoplastic
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 14 Weeks
