302A10879X
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub High Density Connectors DSUB SOLDER PIN ANG 7.98mm STAMPED CONT
PDF
/
Inventory: 6042
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Shell Material Steel
Dielectric Material Polybutylene Terephthalate (PBT), Glass Filled
Housing Material PBT
Shell Material, Finish Steel, Tin Plated
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2007
JESD-609 Code e3
Feature Board Lock
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 26
Color Black
Number of Rows 3
Gender Male
Voltage - Rated 60V
Additional Feature THRD LOCK, CLIP & HIGH DENSITY
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Signal
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 26
Ingress Protection IP20
Terminal Pitch 2.286mm
Current Rating 3A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.556 inch
Number Of PCB Rows 3
PCB Contact Pattern STAGGERED
Body Breadth 0.509 inch
Empty Shell NO
Body Depth 0.646 inch
Rated Current (Signal) 2.5A
Contact Resistance 10mOhm
Insulation Resistance 5000000000Ohm
Flange Feature Mating Side, Female Screwlock (4-40)
Mating Contact Pitch 0.09 inch
Plating Tin
Dielectric Withstanding Voltage 1000VAC V
Connector Style D-Sub, High Density
PCB Contact Row Spacing 2.54 mm
Mating Contact Row Spacing 0.1 inch
Shell Size, Connector Layout 2 DA A High Density
Backset Spacing 0.346 (8.78mm)
Dimensions
Contact Finish Thickness 8.00μin 0.203μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
