3017W5SCT78N40X

Conec
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub Connector
PDF
/
Inventory: 3282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 69.5mm

Technical

Shell Size, Connector Layout 4 DC C - 17W5
Durability 500 Cycles
Number of Ports 1
Connector Style D-Sub, Combo
Flange Feature Housing/Shell (4-40)
Body Breadth 0.509 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Orientation Right Angle
Total Number of Contacts 17
Mixed Contacts YES
Contact Type Coax and Signal
Subcategory D Type Connectors
Number of Rows 2
Color Green
Number of Positions 17 (12 + 5 Coax)
Connector Type Receptacle, Female Sockets
Termination Solder
Number of Terminations 27
Part Status Active
Feature Board Lock, Mounting Brackets
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Shell Material, Finish Steel, Tin Plated
Housing Material Polybutylene
Dielectric Material Polybutylene Terephthalate (PBT), Glass Filled
Number of Pins 17
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material COPPER ALLOY
