241A26320X

Conec
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub Connector
PDF
/
Inventory: 5280
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper Alloy
Mounting Type Board Edge, Through Hole, Right Angle
Dielectric Material Thermoplastic
Shell Material, Finish Steel, Tin Plated

Technical

Operating Temperature -25°C~105°C
Published 2007
Series 241A
Feature Board Lock, Filter, Grounding Indents, Mounting Brackets
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug, Male Pins
Number of Positions 9
Color Black
Number of Rows 2
Voltage - Rated 100V
Contact Type Signal
Current Rating (Amps) 7.5A
Ingress Protection IP20
Contact Finish Gold
Flange Feature Housing/Shell (4-40)
Connector Style D-Sub
Contact Form Machined
Shell Size, Connector Layout 1 DE E
Backset Spacing 0.559 (14.19mm)

Dimensions

Contact Finish Thickness 8.00μin 0.203μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
