DCCM15SBSPN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
ENVIRONMENTAL CLASS D-Sub Connector
PDF
/
Inventory: 7171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 31 Weeks
Physical
Contact Material Copper Alloy
Mounting Type Through Hole
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Dielectric Material Diallyl Phthalate (DAP), Glass Filled
Shell Material, Finish Aluminum Alloy, Nickel Plated, Electroless
Mounting Option 2 JACKPOST
Technical
Operating Temperature -55°C~135°C
Packaging Bulk
Series Dura-Con?
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 15
Number of Rows 2
Additional Feature ENVIRONMENTAL CLASS
Subcategory D Type Connectors
Contact Type Signal
Current Rating (Amps) 3A
Total Number of Contacts 15
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.39 inch
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Body Breadth 0.308 inch
Body Depth 0.355 inch
Contact Resistance 8mOhm
Insulation Resistance 5000000000Ohm
Flange Feature Mating Side, Female Screwlock
Mating Contact Pitch 0.05 inch
Dielectric Withstanding Voltage 600VAC V
Connector Style D-Type, Micro-D
Insertion Force-Max 1.668 N
Withdrawl Force-Min .139 N
Mating Contact Row Spacing 0.05 inch
Contact Form Machined
Shell Size, Connector Layout 0.050 Pitch x 0.043 Row to Row
Dimensions
Contact Finish Thickness 50.0μin 1.27μm
Plating Thickness 50μin
Length - Termination 0.109 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
