56F041-104 image
Favorite
56F041-104 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub Connector
PDF
/
Inventory: 6891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 50.0μin 1.27μm

Technical

Shell Size, Connector Layout 0.050 Pitch x 0.050 Row to Row
Connector Style D-Type, Micro-D
Plating Electroless Nickel
Flange Feature Housing/Shell (Unthreaded)
Empty Shell NO
UL Flammability Code 94V-0
Contact Finish Gold
Current Rating 3A
Total Number of Contacts 31
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Signal
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Capacitance 1.5nF
HTS Code 8536.69.40.30
Voltage - Rated 100V
Gender Male
Number of Rows 2
Number of Positions 31
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Filter
JESD-609 Code e4
Series Micro D
Published 2014
Packaging Tray
Operating Temperature -55°C~125°C

Physical

Shell Material, Finish Aluminum, Nickel Plated, Electroless
Dielectric Material Plastic
Insulation Material GLASS FILLED POLYESTER
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
