8309-8003

3M
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description D-Sub Standard Connectors D-SUB RCPT 9POS W/INSERT
PDF
/
Inventory: 7710
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Length 31.2mm

Technical

Current Rating (Max) 1A
Insulation Insulated
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 26 AWG
Number of Ports 1
Plating Steel, Tin
Housing Color Grey
Number of Contacts 9
Current Rating 1A
Depth 12.4mm
Orientation Right Angle
Pitch 2.76mm
Gender Female
Number of Rows 2
Color Grey
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 9
Connector Type D-Sub, Receptacle, Signal
Termination IDC
Number of Terminations 9
Part Status Active
Published 2009
Packaging Bulk

Physical

Weight 1.610253kg
Housing Material Polybutylene
Shell Material Steel
Insulation Material Glass
Mount Cable, Panel
Contact Plating Gold

Supply Chain

Factory Lead Time 11 Weeks
