1-1532181-8
RoHS
/
Package /
Category Cable Assemblies / D-Sub Cables
Description
M83513/03-C02C, MCKS-C2-B-21P6G1
PDF
/
Inventory: 6202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Copper
Contact Plating Gold
Mounting Type CABLE
Mounting Option 1 HOLE .087-.098
Mounting Option 2 LOCKING
Technical
Packaging Bulk
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Pin, Plug
Number of Positions 21
Number of Rows 2
Gender Male
HTS Code 8536.69.40.30
Subcategory D Type Connectors
Total Number of Contacts 21
Reliability COMMERCIAL
Body Length or Diameter 1.075 inch
Body Breadth 0.298 inch
Lead Length 914.4mm
Body Depth 0.223 inch
Contact Style RND PIN-SKT
Mating Contact Pitch 0.05 inch
ELV Non-Compliant
Plating Nickel
Cable Length 914mm
Contact Pattern STAGGERED
Mating Contact Row Spacing 0.05 inch
Contact Design PREASSEM CONN
Preloaded Yes
Wire Size (Min) 25 AWG
Wire Size (Max) 25 AWG
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
