MDVB1-15PH046
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / D-Sub Cables
Description
MICRO
PDF
/
Inventory: 9416
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Wire Size (Max) 26 AWG
Wire Size (Min) 26 AWG
Mating Contact Row Spacing 0.043 inch
Withdrawl Force-Min .139 N
Insertion Force-Max 2.224 N
Contact Pattern STAGGERED
Contact Finish Termination GOLD
Dielectric Withstanding Voltage 900VAC V
Termination Type WIRE
Body/Shell Style PLUG
Mating Contact Pitch 0.05 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.375 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.218 inch
Operating Temperature (Max) 125°C
Body Length or Diameter 0.938 inch
Reliability COMMERCIAL
Total Number of Contacts 15
Contact Finish - Mating AU ON CU
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Number of Rows 2
ECCN Code EAR99
Part Status Active
Published 2006
Physical
Mounting Option 2 NON-THREADED
Mounting Option 1 HOLE .087-.098
Shell Material ALUMINUM ALLOY
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Mounting Type CABLE
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 15 Weeks
