MDM-9PH003P
RoHS
/
Package /
Category Cable Assemblies / D-Sub Cables
Description
Cable Assembly RG178/U 0.457m 26AWG 9 POS Micro D-Sub PIN Crimp
PDF
/
Buying Options
Total Price: USD $100.21
Unit Price: USD $100.2056
≥1 USD $100.2056
≥10 USD $91.95032
≥100 USD $88.413248
≥500 USD $85.466304
≥1000 USD $80.750912
Inventory: 99
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material COPPER ALLOY
Insulation Material LIQUID CRYSTAL POLYMER
Shell Material ALUMINUM ALLOY
Mounting Option 2 JACKPOST
Technical
Packaging Bulk
Published 2006
Series MDM
JESD-609 Code e4
Part Status Active
Termination Crimp
Connector Type D-Sub
Type D-Type, Micro-D
Number of Positions 9
Color Multiple, Individual
Number of Rows 2
Gender Male
Subcategory D Type Connectors
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 9
Shell Finish CADMIUM/YELLOW CHROMATE
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Max) 125°C
Body Breadth 0.308 inch
Operating Temperature (Min) -55°C
Empty Shell NO
Body Depth 0.23 inch
Rated Current (Signal) 3A
Contact Style Pin
Contact Resistance 8mOhm
Insulation Resistance 5000000000Ohm
Mating Contact Pitch 0.05 inch
Shell Size A
Max Current Rating 3A
Dielectric Withstanding Voltage 600VAC V
Cable Length 457mm
Durability 500 Cycles
Wire/Cable Gauge 26 AWG
Contact Pattern STAGGERED
Insertion Force-Max 2.224 N
Mating Contact Row Spacing 0.043 inch
1st Connector Plug, Male Pins
2nd Connector Individual Wire Leads
Connector Type A D-Sub, Receptacle
Connector Type B Wire Leads
Contact Design PREASSEM CONN
Dimensions
Length 1.50' 457.20mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
