MDM-37SL2
RoHS
/
Package /
Category Cable Assemblies / D-Sub Cables
Description
MICRO 37 F 1.0" UNINS
PDF
/
Inventory: 5041
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.11 inch
Technical
Wire Size (Max) 25 AWG
Wire Size (Min) 26 AWG
Contact Design PREASSEM CONN
Mating Contact Row Spacing 0.1 inch
Withdrawl Force-Min .139 N
Insertion Force-Max 2.224 N
Contact Pattern STAGGERED
Dielectric Withstanding Voltage 600VAC V
Termination Type SOLDER LUG
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 8mOhm
Contact Style Socket
Rated Current (Signal) 3A
Body Depth 0.23 inch
Body Breadth 0.308 inch
Number of Contacts 37
Body Length or Diameter 1.485 inch
Reliability COMMERCIAL
Shell Finish CADMIUM/YELLOW CHROMATE
Contact Finish - Mating AU
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature NO HARDWARE, STANDARD
Gender Female
Number of Rows 2
ECCN Code EAR99
Part Status Active
Physical
Mounting Option 1 HOLE .087-.098
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Mounting Type PANEL
Contact Material COPPER ALLOY
