MDM-31SH001L
RoHS
/
Package /
Category Cable Assemblies / D-Sub Cables
Description
Cable Assembly RG178/U 0.457m 26AWG 31 POS Micro D-Sub SKT Crimp
PDF
/
Inventory: 2649
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 18 inch
Technical
Wire Size (Max) 24 AWG
Wire Size (Min) 32 AWG
Contact Design PREASSEM CONN
Mating Contact Row Spacing 0.043 inch
Withdrawl Force-Min .139 N
Insertion Force-Max 2.224 N
Contact Pattern STAGGERED
Wire/Cable Gauge 26 AWG
Cable Length 457mm
Dielectric Withstanding Voltage 900VAC V
Max Current Rating 3A
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 10mOhm
Contact Style Socket
Rated Current (Signal) 3A
Body Depth 0.225 inch
Operating Temperature (Min) -55°C
Body Breadth 0.308 inch
Operating Temperature (Max) 125°C
Body Length or Diameter 1.335 inch
Reliability COMMERCIAL
Reference Standard UL
Shell Finish CADMIUM/YELLOW CHROMATE
Total Number of Contacts 31
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Gender Female
Number of Rows 2
Connector Type D-Sub
ECCN Code EAR99
Termination Crimp
Part Status Active
JESD-609 Code e4
Published 2006
Packaging Bulk
Physical
Mounting Option 2 JACKSCREW
Mounting Option 1 #2-56
Shell Material ALUMINUM ALLOY
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Number of Pins 31
Mounting Type CABLE
Contact Plating Gold
Contact Material COPPER ALLOY
