MDB1-9PL1K
RoHS
/
Package /
Category Cable Assemblies / D-Sub Cables
Description
Cable Assembly RG178/U 0.012m 25AWG 9 POS Micro D-Sub PIN Crimp
PDF
/
Inventory: 2593
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Wire Size (Max) 25 AWG
Wire Size (Min) 26 AWG
Contact Design PREASSEM CONN
Contact Pattern STAGGERED
Cable Length 12mm
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Contact Style RND PIN-SKT
Body Breadth 0.218 inch
Body Length or Diameter 0.788 inch
Reliability COMMERCIAL
Total Number of Contacts 9
Contact Finish - Mating AU
Subcategory D Type Connectors
Gender Male
Number of Rows 2
Connector Type D-Sub
Termination Crimp
Part Status Active
Packaging Bulk
Physical
Insulation Material DIALLYL PHTHALATE
Number of Pins 9
Mounting Type PANEL
Contact Material COPPER ALLOY
