MD1-9PL1K
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / D-Sub Cables
Description
MICRO 9 M .50" UNINS JACKS
PDF
/
Inventory: 8177
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Wire Size (Max) 25 AWG
Wire Size (Min) 26 AWG
Contact Design PREASSEM CONN
Contact Pattern STAGGERED
Dielectric Withstanding Voltage 600VAC V
Termination Type SOLDER LUG
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 8mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.171 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.215 inch
Operating Temperature (Max) 149°C
Body Length or Diameter 0.512 inch
Reliability COMMERCIAL
Total Number of Contacts 9
Contact Finish - Mating AU
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature JACKSCREW-STANDARD
Number of Rows 2
ECCN Code EAR99
Part Status Active
Physical
Mounting Option 2 JACKSCREW
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Mounting Type PANEL
Contact Material COPPER ALLOY
