M83513/22-B03CP
RoHS
/
Package /
Category Cable Assemblies / D-Sub Cables
Description
Cable Assembly RG178/U 4.368m 24AWG 15 POS Micro D-Sub PL Crimp
PDF
/
Buying Options
Total Price: USD $770.91
Unit Price: USD $770.9064
≥1 USD $770.9064
Inventory: 128
Minimum: 1
-
+
Technical Details
Technical
Mating Contact Pitch 0.05 inch
Body/Shell Style PLUG
Shell Size B
Max Current Rating 3A
Dielectric Withstanding Voltage 600VAC V
Cable Length 4.368m
PCB Contact Row Spacing 2.54 mm
Durability 500 Cycles
Wire/Cable Gauge 24 AWG
Contact Pattern STAGGERED
Insertion Force-Max 2.78 N
Insulation Resistance 5000000000Ohm
Contact Resistance 8mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.355 inch
Empty Shell NO
Operating Temperature (Min) -55°C
Body Breadth 0.308 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 125°C
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Body Length or Diameter 1.39 inch
Reference Standard MIL
Number of Conductors ONE
Shell Finish CADMIUM
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Total Number of Contacts 15
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
HTS Code 8536.69.40.30
Additional Feature STANDARD: MIL-DTL-83513
Gender Male
Number of Rows 2
Connector Type D-Sub
ECCN Code EAR99
Termination Crimp
Part Status Active
Mating Contact Row Spacing 0.043 inch
Withdrawl Force-Min 0.139 N
Physical
Mounting Option 2 JACKPOST
Board Mounting Option HOLE .096
Mounting Style STRAIGHT
Mounting Option 1 #2-56
Shell Material METAL
Insulation Material LIQUID CRYSTAL POLYMER
Number of Pins 15
Mounting Type BOARD
Contact Plating Gold
Supply Chain
Factory Lead Time 5 Weeks
Dimensions
Length - Termination 0.172 inch
Plating Thickness 50μin
