787962-1
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Conn VHDCI RCP 68/68 POS 1.6mm Solder RA Thru-Hole 136 Terminal 2 Port
PDF
/
Inventory: 7021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Length 42.7mm
Technical
Contact Pattern RECTANGULAR
Connector Style Outer Shroud Contacts
Max Voltage Rating (AC) 30V
Flange Feature Housing/Shell (M2.6)
Insulation Resistance 500000000Ohm
Contact Style BELLOWED TYPE
Empty Shell NO
Housing Color Black
UL Flammability Code 94V-0
Body Breadth 0.466 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4+4
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish NICKEL
Reach Compliance Code not_compliant
Depth 21.16mm
Orientation Right Angle
Total Number of Contacts 68
Pitch 1.6mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Number of Positions 68, 68
Connector Type Stacked, 2 Receptacles
ECCN Code EAR99
Termination Solder
Number of Terminations 136
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Board Lock
JESD-609 Code e0
Series CHAMP .031
Published 2005
Physical
Housing Material Thermoplastic
Shell Material CARBON STEEL
Number of Pins 1
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 11 Weeks
