787801-1
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN STCK PLUG 68/68POS STR IDC
PDF
/
Inventory: 4907
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 68
Shell Material CARBON STEEL
Housing Material Plastic
Technical
Series CHAMP .031
JESD-609 Code e0
Feature Jackscrew, Screwlock, Shielded
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Stacked, 2 Plugs
Number of Positions 68, 68
Number of Rows 2
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 68
Reach Compliance Code unknown
Shell Finish TIN
Number of Conductors 1
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
UL Flammability Code 94V-0
Housing Color Black
Empty Shell NO
Flange Feature Housing/Shell (Unthreaded)
Connector Style Center Strip Contacts
Mating Contact Row Spacing 0.031 inch
Insulator Color NATURAL
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
