787653-1
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN CHAMP RCPT RTANG 20 POS PCB
PDF
/
Buying Options
Total Price: USD $28.45
Unit Price: USD $28.451856
≥1 USD $28.451856
≥200 USD $11.352646
≥500 USD $10.973218
≥800 USD $10.785474
Inventory: 7238
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 35 Weeks
Physical
Contact Material Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polymer
Technical
Published 2005
Series CHAMP .050 I
JESD-609 Code e0
Feature Board Lock, Latch Lock
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Termination Solder
Connector Type Receptacle
Type Board to Board
Number of Positions 20
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Female
Subcategory Other Rectangular Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 20
Orientation Right Angle
Depth 18.97mm
Current Rating 3A
Reference Standard UL
Contact Finish Gold
Voltage - Rated AC 100V
Reliability COMMERCIAL
Lead Pitch 1.27mm
Body Breadth 0.388 inch
UL Flammability Code 94V-0
Empty Shell NO
Rated Current (Signal) 1A
Contact Style BELLOWED TYPE
Contact Resistance 35mOhm
Insulation Resistance 1GOhm
Max Voltage Rating (AC) 250V
Dielectric Withstanding Voltage 300VAC V
Connector Style Outer Shroud Contacts
Number of Ports 1
Durability 500 Cycles
Contact Pattern RECTANGULAR
Contact Design PREASSEM CONN
Dimensions
Length 29.88mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
