787254-1
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
I/O Connectors 68P CHAMP RECEPT THRU-HOLE
PDF
/
Inventory: 3977
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Shell Material STEEL
Housing Material Thermoplastic
Technical
Published 2003
Series CHAMP .031
Feature Board Guide, Board Lock, Shielded
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 68
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Female
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 800μm
Total Number of Contacts 68
Orientation Right Angle
Reach Compliance Code not_compliant
Current Rating 1.5A
Shell Finish NICKEL
Reference Standard UL
Contact Finish Gold
Voltage - Rated AC 30V
Reliability COMMERCIAL
Number Of PCB Rows 4
Lead Pitch 2mm
PCB Contact Pattern STAGGERED
UL Flammability Code 94V-0
Empty Shell NO
Contact Style BELLOWED TYPE
Insulation Resistance 500MOhm
Flange Feature Housing/Shell (M2.6)
Connector Style Outer Shroud Contacts
Number of Ports 1
Contact Pattern RECTANGULAR
Withdrawl Force-Min .0834 N
Dimensions
Height 5mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 3μin
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
