5917738-4 image
Favorite
5917738-4 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description I/O Connectors CHAMP REC HDR ASSY 050 FMS 26P
PDF
/
Buying Options
Total Price: USD $5.87
Unit Price: USD $5.8696
≥1 USD $5.8696
≥10 USD $5.11368
≥100 USD $4.97904
≥500 USD $4.73829
Inventory: 2291
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Shell Material Steel
Housing Material PBT
PCB Mounting Orientation Right Angle

Technical

Published 2005
Series CHAMP .050 II
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 26
Termination Solder
Connector Type Receptacle
Number of Positions 26
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Receptacle
Pitch 1.27mm
Orientation Right Angle
Depth 16.84mm
Contact Finish Gold
Number of Contacts 26
Housing Color Black
Lead Length 3.1mm
Flange Feature Housing/Shell (M2.6)
ELV Compliant
Max Voltage Rating (AC) 250V
Plating Copper, Nickel
Connector Style Outer Shroud Contacts
Number of Ports 1
Hole Diameter 2.7 mm
Preloaded Yes

Dimensions

Length 37.16mm
Contact Finish Thickness 3.94μin 0.10μm
PCB Thickness 1.66mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
