557102-9
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN BTB PLUG 50POS VERT SOLDER
PDF
/
Inventory: 9122
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mount Through Hole
Mounting Type Through Hole
Housing Material Plastic
Technical
Published 2005
Series CHAMP .050 I
Feature Board Guide, Board Lock
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug
Type Board to Board
Number of Positions 50
Color Black
Number of Rows 2
Subcategory D Type Connectors
Total Number of Contacts 50
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.697 inch
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 85°C
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.391 inch
Rated Current (Signal) 1A
Contact Style BELLOWED TYPE
Contact Resistance 35mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.05 inch
Body/Shell Style RECEPTACLE
Connector Style Center Strip Contacts
PCB Contact Row Spacing 1.905 mm
Contact Pattern RECTANGULAR
Insertion Force-Max .8896 N
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.106 inch
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
