555520-2
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
I/O Connectors RA 36P STANDARD 4-40 metl shield board lk
PDF
/
Inventory: 5531
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Panel Thickness 1.57mm
Contact Finish Thickness Flash
Width 18mm
Technical
Contact Pattern RECTANGULAR
Connector Style Outer Shroud Contacts
ELV Non-Compliant
Body/Shell Style PLUG
Flange Feature Housing/Shell (4-40)
Contact Style BELLOWED TYPE
Rated Current (Signal) 3.5A
Body Depth 0.71 inch
Operating Temperature (Min) -40°C
Body Breadth 0.64 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Shielding Shielded
Orientation Right Angle
Total Number of Contacts 36
Pitch 2.16mm
Subcategory D Type Connectors
Gender Female
Number of Rows 2
Color Black
Number of Positions 36
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Bail Lock, Shielded
Series CHAMP .085
Published 1997
Physical
Housing Material Polyester
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Gold, Tin
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 3 Weeks
