554923-1
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CHAMP .085 Non-RoHS Compliant COMMERCIAL UL CSA Receptacle Connector UL94V-0 105C 3.5A 0.64inch
PDF
/
Inventory: 3301
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material COPPER ALLOY
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Housing Material Polyester
Technical
Published 1997
Series CHAMP .085
JESD-609 Code e3
Feature Board Lock, Shielded
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 24
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.16mm
Total Number of Contacts 24
Orientation Right Angle
Reference Standard UL, CSA
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Body Breadth 0.64 inch
Contact Gender FEMALE
Rated Current (Signal) 3.5A
Contact Style BELLOWED TYPE
Flange Feature Housing/Shell (6-32)
Connector Style Outer Shroud Contacts
Number of Ports 1
Contact Pattern RECTANGULAR
Dimensions
Length 56mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
