553444-2
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Headers & Wire Housings PLUG 24P VERT PCB
PDF
/
Inventory: 1942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 0.18 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Insulator Color BLACK
Mating Contact Row Spacing 0.16 inch
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 4.064 mm
Connector Style Center Strip Contacts
Dielectric Withstanding Voltage 1000VAC V
Flange Feature Housing/Shell (4-40)
Contact Resistance 6.5mOhm
Rated Current (Signal) 3A
Empty Shell NO
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender Male
Body Breadth 0.595 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Orientation Straight
Total Number of Contacts 24
Pitch 2.16mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature ACTION PIN; CHAMP-LOK
Number of Rows 2
Number of Positions 24
Connector Type Plug
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series CHAMP .085
Published 2013
Physical
Housing Material Polyester
Mounting Type Through Hole
Mount Through Hole
Contact Material COPPER ALLOY
Alternative Model
