552390-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN CHAMP 50 POS PLUG SCREW
PDF
/
Buying Options
Total Price: USD $9.16
Unit Price: USD $9.160439
≥1 USD $9.160439
≥10 USD $8.641923
≥100 USD $8.152755
≥500 USD $7.691279
≥1000 USD $7.255921
Inventory: 3573
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material POLYPHENYLENE OXIDE
Housing Material PPO
Technical
Published 1997
Series CHAMP .085
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 50
Termination IDC
Connector Type Plug
Max Operating Temperature 75°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Gender Male
Voltage - Rated 250V
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.16mm
Total Number of Contacts 50
Orientation Right Angle
Shielding Unshielded
Depth 15.24mm
Current Rating 3.5A
Contact Finish Gold
Reliability COMMERCIAL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.6 inch
UL Flammability Code 94V-0
Empty Shell NO
Contact Style CENTRONIC
Flange Feature Housing/Shell (4-40)
ELV Compliant
Wire/Cable Type Strand
Connector Style Center Strip Contacts
Number of Ports 1
Contact Pattern RECTANGULAR
Sealable No
Circuit Application Signal
Dimensions
Length 83.31mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
