5084488-5 image
Favorite
5084488-5 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description CONN SCA-2 PLUG 80POS VERT SLDR
PDF
/
Inventory: 6947
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 66.5mm

Technical

Number of Ports 1
Connector Style Center Strip Contacts
Max Voltage Rating (AC) 250V
ELV Compliant
Empty Shell NO
UL Flammability Code 94V-0
Contact Finish Gold
Depth 7mm
Orientation Straight
Total Number of Contacts 80
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 80
Type SCA-2
Connector Type Plug
Termination Solder
Number of Terminations 160
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Guide, Board Lock
JESD-609 Code e3
Series CHAMP .050 I
Published 2008

Physical

Housing Material Polymer
Mounting Type Through Hole
Mount Through Hole
Contact Material Bronze
