5-5175474-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Conn SCSI RCP 30 POS 2.54mm Solder RA Thru-Hole 60 Terminal 1 Port
PDF
/
Inventory: 3881
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length - Tail 3.1242mm
Plating Thickness 1μm
Contact Finish Thickness 30.0μin 0.76μm
Height 7.493mm
Technical
Stackable No
Contact Current Rating 1A
Number of Ports 1
Connector Style Outer Shroud Contacts
ELV Compliant
Empty Shell NO
Lead Length 3.1mm
UL Flammability Code 94V-0
Contact Finish Gold
Depth 17.46mm
Orientation Right Angle
Total Number of Contacts 30
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Number of Rows 2
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Number of Positions 30
Type Board to Board, High Density
Connector Type Receptacle
Termination Solder
Number of Terminations 60
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Lock
JESD-609 Code e3
Series CHAMP .050 I
Published 2004
Physical
PCB Mounting Orientation Right Angle
Housing Material Nylon
Shell Material GLASS FILLED POLYAMIDE66
Contact Shape Square
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 30 Weeks
