3-5175474-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN BTB HD RCPT 30POS R/A SLDR
PDF
/
Buying Options
Total Price: USD $6.82
Unit Price: USD $6.82
≥1 USD $6.82
≥10 USD $5.94616
≥100 USD $5.790048
≥500 USD $5.633408
≥1000 USD $5.28924
≥3000 USD $5.25793
Inventory: 2285
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mounting Type Through Hole, Right Angle
Contact Shape Square
Shell Material GLASS FILLED POLYAMIDE66
Housing Material Nylon
PCB Mounting Orientation Right Angle
PCB Mount Alignment Without
Technical
Published 2004
Series CHAMP .050 I
JESD-609 Code e3
Feature Board Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Type Board to Board, High Density
Number of Positions 30
Max Operating Temperature 185°C
Min Operating Temperature -67°C
Color Black
Number of Rows 2
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 30
Orientation Right Angle
Contact Finish Gold
UL Flammability Code 94V-0
Lead Length 3.1mm
Empty Shell NO
Operating Supply Voltage 250V
Insulation Resistance 1MOhm
ELV Compliant
Connector Style Outer Shroud Contacts
Sealable No
Contact Current Rating 1A
Circuit Application Signal
Mating Alignment With
Dimensions
Height 7.493mm
Contact Finish Thickness 20.0μin 0.51μm
Plating Thickness 1μm
Contact Finish Thickness - Mating 500 nm
Length - Tail 3.1242mm
PCB Thickness 12.7mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
