2-175677-7
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Headers & Wire Housings CABLE PLUG 50P Series II
PDF
/
Inventory: 3607
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material STEEL
Housing Material Plastic
Technical
Published 2003
Series CHAMP .050 II
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
ECCN Code EAR99
Connector Type Plug
Number of Positions 50
Number of Rows 2
HTS Code 8536.69.40.30
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 50
Reach Compliance Code unknown
Shell Finish NICKEL
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Max) 85°C
Body Breadth 0.315 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Housing Color Black
Empty Shell NO
Rated Current (Signal) 1A
Contact Resistance 35mOhm
Mating Contact Pitch 0.05 inch
Connector Style Center Strip Contacts
Contact Pattern RECTANGULAR
Withdrawl Force-Min .1946 N
Mating Contact Row Spacing 0.1 inch
Contact Design PREASSEM CONN
Wire Size (Min) 30 AWG
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
