1734101-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Board to Board & Mezzanine Connectors 050 RCPT 80pos 30 Au
PDF
/
Inventory: 6844
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 62.15mm
Technical
Number of Ports 1
Connector Style Outer Shroud Contacts
Number of Contacts 80
Contact Finish Gold
Depth 7.1mm
Orientation Straight
Pitch 2.54mm
Number of Rows 2
Number of Positions 80
Type Board to Board
Connector Type Receptacle
Termination Solder
Number of Terminations 160
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Board Lock
Series CHAMP .050 I
Published 2009
Physical
Housing Material Polyphthalamide
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 11 Weeks
