1734101-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Conn SCSI RCP 50 POS 2.54mm Solder ST Thru-Hole 50 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $5.08
Unit Price: USD $5.0776
≥1 USD $5.0776
≥10 USD $4.44488
≥100 USD $4.328544
≥500 USD $4.235572
≥1000 USD $3.979633
≥3000 USD $3.956313
Inventory: 1081
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Dimensions
PCB Thickness 1.6002mm
Length - Tail 2.535479mm
Contact Finish Thickness - Mating 762 nm
Plating Thickness 30μin
Contact Finish Thickness Flash
Length 43.1mm
Height 9.9822mm
Technical
Stackable No
Circuit Application Signal
Contact Current Rating 1A
Insertion Force-Max .834 N
Contact Pattern RECTANGULAR
Number of Ports 1
Connector Style Outer Shroud Contacts
Max Voltage Rating (AC) 250V
ELV Compliant
Row Spacing 1.904 mm
Insulation Resistance 4MOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 1A
Operating Supply Voltage 250V
Empty Shell NO
Lead Length 2.54mm
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Depth 7.1mm
Orientation Vertical
Total Number of Contacts 200
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
Gender Female
Number of Rows 2
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Number of Positions 50
Type Board to Board
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Board Lock
Series CHAMP .050 I
Published 1999
Physical
PCB Mount Retention With
Housing Material Resin
Shell Material POLYPHTALAMIDE
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 12 Weeks
