1734099-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN BTB PLUG 40POS R/A SOLDER
PDF
/
Buying Options
Total Price: USD $4.66
Unit Price: USD $4.6552
≥1 USD $4.6552
≥10 USD $4.07704
≥100 USD $3.97056
≥500 USD $3.885297
≥1000 USD $3.629085
≥3000 USD $3.394274
Inventory: 624
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Stack Height 13.2mm
PCB Thickness 1.27mm
Length - Tail 3.094482mm
Contact Finish Thickness - Mating 50 nm
Plating Thickness 3.81μm
Contact Finish Thickness Flash
Length 35.33mm
Height 7.48665mm
Technical
Mating Alignment With
Contact Design PREASSEM CONN
Circuit Application Signal
Contact Current Rating 1A
Sealable No
Insertion Force-Max .8896 N
Contact Pattern RECTANGULAR
Durability 500 Cycles
Number of Ports 1
Connector Style Center Strip Contacts
Dielectric Withstanding Voltage 750VAC V
Max Voltage Rating (AC) 250V
Row Spacing 1.90246 mm
Insulation Resistance 4MOhm
Contact Style CENTRONIC
Rated Current (Signal) 1A
Empty Shell NO
Lead Length 3.1mm
UL Flammability Code 94V-0
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Depth 17.46mm
Orientation Right Angle
Total Number of Contacts 140
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Other Rectangular Connectors
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Number of Positions 40
Type Board to Board
Connector Type Plug
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock
JESD-609 Code e3
Series CHAMP .050 I
Published 1999
Physical
PCB Mount Alignment Without
PCB Mounting Orientation Right Angle
Housing Material Polymer
Contact Shape Square
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
