1-749611-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN SCSI RCPT 26POS PNL MNT IDC
PDF
/
Buying Options
Total Price: USD $14.34
Unit Price: USD $14.3352
≥1 USD $14.3352
≥10 USD $14.03864
≥100 USD $13.664992
≥500 USD $12.993024
≥1000 USD $11.723624
≥3000 USD $11.648982
Inventory: 913
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Bronze
Mount Cable, Panel
Mounting Type Panel Mount
Shell Material Steel
Housing Material Thermoplastic
Technical
Published 2004
Series AMPLIMITE .050 III
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
ECCN Code EAR99
Connector Type Receptacle
Type SCSI
Number of Positions 26
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Female
HTS Code 8536.69.40.30
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 26
Orientation Right Angle
Shielding Unshielded
Current Rating 1A
Contact Finish Gold
UL Flammability Code 94V-0
Empty Shell NO
Flange Feature Housing/Shell (2-56); Latchblocks, Rails
ELV Compliant
Plating Copper, Nickel
Wire/Cable Type Ribbon
Connector Style Outer Shroud Contacts
Number of Ports 1
Sealable No
Circuit Application Signal
Insulation Diameter 910 μm
Preloaded Yes
Dimensions
Length 37.21mm
Width 10.3mm
Contact Finish Thickness Flash
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
