1-5175677-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Headers & Wire Housings .050 PLUG KIT 80P
PDF
/
Inventory: 929
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin, Gold
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Housing Material Thermoplastic
Technical
Published 2005
Series CHAMP .050 II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Plug
Number of Positions 80
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 80
Orientation Right Angle
Shielding Unshielded
Depth 8mm
Current Rating 500mA
Contact Finish Gold
UL Flammability Code 94V-0
Empty Shell NO
ELV Compliant
Max Voltage Rating (AC) 250V
Connector Style Center Strip Contacts
Number of Ports 1
Sealable No
Circuit Application Signal
Insulation Diameter 700 μm
Dimensions
Length 60.3mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 300 nm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
