1-229913-4 image
Favorite
1-229913-4 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description CHAMP .085 Non-RoHS Compliant 2013 GENERAL PURPOSE Receptacle Connector 30.0muin 0.76mum
PDF
/
Inventory: 3869
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Connector Style Outer Shroud Contacts
Flange Feature Housing/Shell (4-40)
Empty Shell NO
Housing Color Grey
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Reach Compliance Code unknown
Total Number of Contacts 50
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature CHAMP-LOK
Number of Rows 2
Number of Positions 50
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Backshell, Cable Clamp, Dust Cover, Mounting Hardware
Series CHAMP .085
Published 2013

Physical

Housing Material Plastic
Shell Material POLYPHENYLENE OXIDE
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material NOT SPECIFIED
