1-1734101-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Board to Board & Mezzanine Connectors 050 RCPT 160P 30 Au
PDF
/
Inventory: 5263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
PCB Thickness 1.6002mm
Length - Tail 2.535479mm
Contact Finish Thickness - Mating 760 nm
Contact Finish Thickness Flash
Height 9.9822mm
Technical
Stackable No
Mating Alignment With
Circuit Application Signal
Contact Current Rating 1A
Sealable No
Connector Style Outer Shroud Contacts
ELV Compliant
Row Spacing 1.904 mm
Insulation Resistance 4MOhm
Operating Supply Voltage 250V
Lead Length 2.54mm
Housing Color Black
Number of Contacts 160
Contact Finish Gold
Orientation Vertical
Pitch 1.27mm
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Number of Positions 160
Type Board to Board
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Board Lock
Series CHAMP .050 I
Published 1999
Physical
PCB Mount Alignment With
PCB Mount Retention With
PCB Mounting Orientation Vertical
Housing Material Resin
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 11 Weeks
