2-552271-1
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
ASSY, RCPT, 14 POS, B SLOT
PDF
/
Buying Options
Total Price: USD $6.89
Unit Price: USD $6.893882
≥1 USD $6.893882
≥10 USD $6.503669
≥100 USD $6.135533
≥500 USD $5.788237
≥1000 USD $5.4606
Inventory: 1733
Minimum: 1
-
+
Technical Details
Technical
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.6 inch
Contact Gender Female
Housing Color Black
Empty Shell NO
Contact Style BELLOWED TYPE
ELV Compliant
Wire/Cable Type Round
Number of Ports 1
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 26 AWG
Contact Pattern RECTANGULAR
Reliability COMMERCIAL
Reference Standard UL
Depth 15.24mm
Shielding Unshielded
Orientation Right Angle
Total Number of Contacts 14
Pitch 2.16mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature CHAMP
Number of Rows 2
Connector Type Receptacle
ECCN Code EAR99
Termination IDC
Number of Terminations 14
Pbfree Code yes
Dimensions
Length 44.45mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material Thermoplastic
Mount Cable, Free Hanging
Contact Plating Gold
Contact Material NOT SPECIFIED
