87552-0801
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
EBBI STAGGERED CONFIGURATION Centronic D-Shaped Connector
PDF
/
Inventory: 1496
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.11 inch
Plating Thickness 30μin
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Withdrawl Force-Min 11.5648 N
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 1.905 mm
Dielectric Withstanding Voltage 500VAC V
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 1A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Breadth 0.301 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern STAGGERED
Number of Contacts 80
Number Of PCB Rows 4
Reliability COMMERCIAL
Reference Standard UL, CSA
Reach Compliance Code unknown
Orientation Right Angle
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
HTS Code 8536.69.40.40
Additional Feature EBBI, STAGGERED CONFIGURATION
Gender Female
Number of Rows 2
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Physical
Housing Material Plastic
Mount Through Hole
Contact Material NOT SPECIFIED
