71743-1082
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Board to Board & Mezzanine Connectors Obsolete
PDF
/
Inventory: 6574
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.07 inch
Plating Thickness 30μin
Technical
Withdrawl Force-Min .139 N
Insertion Force-Max .8896 N
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 1.905 mm
Dielectric Withstanding Voltage 500VAC V
Mating Contact Pitch 0.05 inch
Insulation Resistance 1000000000Ohm
Contact Style BELLOWED TYPE
Rated Current (Signal) 1A
Body Depth 0.453 inch
Empty Shell NO
Housing Color Black
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern STAGGERED
Number of Contacts 80
Number Of PCB Rows 4
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 1A
Reach Compliance Code unknown
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Voltage - Rated 30V
Gender Female
Number of Rows 2
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Physical
Housing Material Plastic
Shell Material LIQUID CRYSTAL POLYMER
Mount Through Hole
Contact Plating Gold
Contact Material NOT SPECIFIED
