15-92-3080
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
EBBI POLARIZED Centronic D-Shaped Connector
PDF
/
Inventory: 7545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 30μin
Length 62.1mm
Technical
Wire Size (Max) 30 AWG
Wire Size (Min) 30 AWG
Contact Design PREASSEM CONN
Insertion Force-Max .8896 N
Contact Pattern RECTANGULAR
Number of Ports 1
Dielectric Withstanding Voltage 500VAC V
Number of Circuits 68
Body/Shell Style RECEPTACLE
Contact Style CENTRONIC
Rated Current (Signal) 1A
Housing Color Black
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 1A
Depth 8.76mm
Orientation Straight
Total Number of Contacts 80
Pitch 2.54mm
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
HTS Code 8536.69.40.40
Additional Feature EBBI, POLARIZED
Gender Female
Number of Rows 2
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination IDT
Number of Terminations 80
Part Status Discontinued
Published 2004
Physical
Housing Material Polymer
Mount Cable
Contact Plating Gold
Contact Material NOT SPECIFIED
