15-92-1130
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Board to Board & Mezzanine Connectors EBBI 50D RECPT 130P
PDF
/
Inventory: 7917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Thermoplastic
Technical
Published 2009
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 130
Number of Rows 2
Gender Female
Voltage - Rated 30V
Additional Feature LOW PROFILE, STAGGERED CONFIGURATION
HTS Code 8536.69.40.40
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 130
Orientation Vertical
Current Rating 1A
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 105°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Housing Color Black
Body Depth 0.13 inch
Rated Current (Signal) 1A
Contact Style BELLOWED TYPE
Contact Resistance 10mOhm
Dielectric Withstanding Voltage 700VAC V
PCB Contact Row Spacing 1.905 mm
Contact Pattern RECTANGULAR
Insertion Force-Max .8896 N
Withdrawl Force-Min .139 N
Halogen Free Low Halogen
Glow Wire Compliant Non-compliant
Dimensions
Height 9.8mm
Length 94mm
Width 7mm
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
