0875520807
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN RECEPT RT ANG 80POS 1.27MM
PDF
/
Inventory: 5943
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.11 inch
Plating Thickness 30μin
Contact Finish Thickness 29.5μin 0.75μm
Technical
Insulator Color BLACK
Durability 500 Cycles
Connector Style Outer Shroud Contacts
Mating Contact Pitch 0.05 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Rated Current (Signal) 1A
Operating Temperature (Min) -55°C
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Number of Conductors ONE
Total Number of Contacts 80
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Number of Positions 80
Type Board to Board
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
JESD-609 Code e3
Series EBBI 87552
Physical
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Through Hole, Right Angle
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 9 Weeks
