0743370054
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Conn VHDCI RCP 136 POS 1.6mm Solder RA Thru-Hole 136 Terminal Ultra+? 1 Port Tray
PDF
/
Inventory: 7825
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness Flash
Length 42.7mm
Technical
Number of Ports 1
Connector Style Outer Shroud Contacts
Max Voltage Rating (AC) 30V
Flange Feature Mating Side (M2)
Insulation Resistance 500MOhm
Empty Shell NO
Number of Contacts 136
Lead Pitch 800μm
Contact Finish Gold
Current Rating 500mA
Depth 24.82mm
Orientation Right Angle
Pitch 1.6mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.30
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Number of Positions 68, 68
Type SCSI+, VHDCI
Connector Type Stacked, 2 Receptacles
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock, Cover, Shielded
Series Ultra+ VHDCI 74337
Physical
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
