0714300005
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Conn VHDCI RCP 68 POS 0.8mm Solder RA Thru-Hole 68 Terminal Ultra+? 1 Port Tube
PDF
/
Inventory: 966
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Shell Material POLYETHYLENE
Housing Material Polymer
Technical
Series Ultra+ VHDCI 71430
Feature Board Lock, Shielded
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Type SCSI+, VHDCI
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Number of Rows 2
HTS Code 8536.69.40.30
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 800μm
Orientation Right Angle
Depth 14.65mm
Reach Compliance Code compliant
Current Rating 500mA
Contact Finish Gold
Lead Pitch 800μm
Number of Contacts 68
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Flange Feature Housing/Shell (M2.6)
Max Voltage Rating (AC) 30V
Connector Style Outer Shroud Contacts
Number of Ports 1
Dimensions
Length 42.7mm
Contact Finish Thickness Flash
Compliance
RoHS Status Non-RoHS Compliant
