0015921440
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Centronic D-Shaped Connector
PDF
/
Inventory: 4599
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Insulator Color BLACK
Contact Pattern RECTANGULAR
Connector Style Outer Shroud Contacts
Dielectric Withstanding Voltage 700VAC V
Mating Contact Pitch 0.05 inch
Contact Resistance 10mOhm
Rated Current (Signal) 1A
Operating Temperature (Max) 105°C
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Number of Conductors ONE
Total Number of Contacts 40
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Number of Positions 40
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Board Lock
JESD-609 Code e3
Series EBBI 71660
Physical
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Through Hole
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 8 Weeks
